/Volvo V60 R-Design

Volvo V60 R-Design

Volvo V60 R Design 1 at Volvo V60 R Design

Along with the S60 sedan, Volvo also prepared an R-Design version of the car’s station wagon variant, the V60. In terms of styling and interior, the V60 gets the same treatment as the S60 which means new front and rear skirts, redesigned grille, 18-inch wheels, twin tailpipes, and sport seats. You can find further details about that Here. In this article, we want to have a closer look on the car’s improved handling by reviewing the details of upgrades for the suspension and steering system. So hit the jump and see why you have get an R-Design if you want a Volvo S60 or V60!

Volvo V60 R Design 2 at Volvo V60 R Design
Volvo V60 R Design 3 at Volvo V60 R Design

“The challenge was to boost the dynamics without making the chassis feel raw. If the chassis is too firm, even smooth tarmac can feel bumpy. We wanted a distinct yet plush feel.” relates Stefan Sällqvist.

Strut brace gives more direct steering feel

The chassis team fitted what is known as a strut brace under the bonnet, that is to say a bar that ties together the suspension strut towers. This is a classic method of stiffening up the body structure.

“The car now has a more solid feel to it, which in turn helps make the steering feel even more responsive with a distinctive contact with the road,” explains Stefan Sällqvist.

Monotube damping at the rear

At the rear the Volvo S60 R-Design and Volvo V60 R-Design feature monotube dampers. Unlike the twin-tube dampers previously used, the monotube system features compression and return damping via the same valve. This gives shorter, faster fluid flow, which in turn means the damper responds more quickly.

“This higher operating speed takes care of the initial roll tendency which can be felt just as you turn the steering-wheel. It’s an effective way to improve the response and the connected feel” says Stefan Sällqvist.

Shorter, stiffer springs

The front and rear springs have been shortened by 15 mm to give the car more attitude. What is more, spring stiffness is 15 percent higher compared to the dynamic chassis in the S60 and V60.

“This makes the car easier to control and reduces any tendency to lurch. This is an area that requires true fingertip sensitivity in order to find the right blend of dynamics and comfort. If you go too far the car feels bumpy even on smooth surfaces. We’ve invested a whole lot of time and effort in finding the ideal balance,” says Stefan Sällqvist.

Even firmer bushings

The bushings with which the rear dampers are attached to the body are 20 percent stiffer compared with the dynamic chassis in the S60 and V60.

The front tie-blade bushing, that is to say the attachment in the rear of the car, is a massive 400 percent stiffer than before to counteract wheel bouncing and shaking.

“The stiffer the bushing, the less oscillation and roll. Movements are more controlled. This is clearly noticeable inside the car,” says Stefan Sällqvist.

The new Corner Traction Control system provides even smoother progress in curves

Just like in the standard versions, the chassis in the S60 and V60 R-Design is backed up by a range of electronic systems that sharpen the sporty driving experience still further.

Corner Traction Control is a new feature that uses torque vectoring to make for smoother cornering. The technology is a further refinement of the DSTC anti-spin system.

When taking a curve, the car’s inner wheel is braked so more power is transferred to the outer wheel. This gives the driver a tighter line in the curve, with reduced understeering tendency.

The DSTC (Dynamic Stability and Traction Control) system has several functions that improve driving and safety properties, such as:

  • Advanced Stability Control. With a new gyroscopic roll-angle sensor it is possible to identify any skidding tendency at a very early stage. This means that the anti-spin system can deploy faster and with greater precision. Advanced Stability Control provides a huge improvement in driving properties and in emergency avoidance manoeuvres during dynamic driving involving considerable lateral forces.
  • Engine Drag Control. Prevents the wheels from losing their grip during engine braking on a slippery surface.
  • The DSTC system also has a sports setting that makes it possible for the driver to drive more actively. By disabling the anti-spin function, the car allows more pronounced oversteer.
